Mainly used for conveyance of diesel, gasoline, lubricants and other mineral oils.
Construction:
Tube: NBR synthetic rubber, black color.
Reinforcement: High tensile synthetic yarn, single/double yarn braided or spiraled.
Cover: NR/SBR synthetic rubber, black, red and green in colors etc.
Characteristics:Oil resistant, abrasion resistant, weather resistant and ozone resistant. It is flexible, light in weight, antibending, less distortion.
Temperature:-30℃ - +80℃
Standard Length:50m, 100m
| tem code | I.D. | O.D. | Length | Measurement | Weight | |||||
| Working | Burst | |||||||||
| Pressure | Pressure | |||||||||
| inch | mm | mm | bar | psi | bar | psi | m | m3/roll | kg/m | |
| RFS-05 | 3/16" | 5 | 12 | 20 | 300 | 60 | 900 | 100 | 410x410x100 | 0.15 |
| RFS-06 | 1/4" | 6 | 13 | 20 | 300 | 60 | 900 | 100 | 440x440x110 | 0.17 |
| RFS-08 | 5/16" | 8 | 15 | 20 | 300 | 60 | 900 | 100 | 490x490x120 | 0.22 |
| RFS-10 | 3/8" | 10 | 17 | 20 | 300 | 60 | 900 | 100 | 500x500x125 | 0.25 |
| RFS-13 | 1/2" | 13 | 22 | 20 | 300 | 60 | 900 | 50 | 480x480x135 | 0.46 |
| RFS-16 | 5/8" | 16 | 25 | 20 | 300 | 60 | 900 | 50 | 480x480x150 | 0.52 |
| RFS-19 | 3/4" | 19 | 29 | 20 | 300 | 60 | 900 | 50 | 520x520x185 | 0.64 |
| RFS-25 | 1" | 25 | 36 | 20 | 300 | 60 | 900 | 50 | 590x590x210 | 0.85 |
| RFS-32 | 1-1/4" | 32 | 43 | 10 | 150 | 30 | 450 | 50 | 0.17 | 1.2 |
| RFS-38 | 1-1/2" | 38 | 50 | 10 | 150 | 30 | 450 | 50 | 0.19 | 1.39 |
| RFS-51 | 2" | 51 | 65 | 10 | 150 | 30 | 450 | 50 | 0.41 | 1.8 |
Our oil hose adopts a multi-layer structure to ensure safety and durability.
The inner hose is made of oil-resistant rubber, which can transport oil media for a long time and is not easy to swell or dissolve.
The reinforcement layer uses high-strength steel wire or textile layer, which can withstand high-pressure liquid transportation.
The outer layer is wear-resistant rubber or textile cover or stainless steel braided oil hose. The smooth surface or wrapped surface can be customized according to the needs. Available in red, yellow, blue or other custom colors. It is resistant to ozone and weather, has a long service life, and is suitable for harsh working conditions.
High-Quality Materials: This rubber hose is made from high-quality materials, ensuring durability and resistance to oil, diesel, and gasoline, making it a reliable choice for various applications.
Customized Size Options: Available in a customized size , this hose can be tailored to meet specific needs, whether for a motorcycle, industrial equipment, or other applications, as requested by the user.
Environmental Protection: The rubber hose is designed with environmental protection in mind, featuring an odorless and non-toxic material that minimizes its impact on the environment.
Multi-Purpose Use: Suitable for use with diesel, gasoline, and other fuels, this hose is a versatile solution for various applications, including motorcycles, industrial equipment, and more.
Long-Lasting Performance: With its high-quality materials and durable construction, this rubber hose provides long-lasting performance and resistance to wear and tear, ensuring a reliable and efficient fuel supply system.
