Aliases: Flexible Clear PVC Hoses, Flexible Transparent PVC Tubing, Clear PVC plastic tubing, Clear Vinyl Pvc tubing,Transparent pipeline.
Applications of PVC Clear Hose:
PVC transparent hose is used for conveying water,oil,gas under normal working condition in factories,farm,ship,building and family.
A PVC clear hose is a type of hose made from transparent PVC (polyvinyl chloride) material. lt is designed to providevisibility and easy monitoring of the contents or flow passing through the hose. The clear nature of the hose allowsusers to visually inspect and track the movement of liquids, gases, or other materials.
Characteristics of PVC Clear Hose:
PVC clear hose is flexible,durable,non-toxic,without odor,and resistant too high pressure and erosion.By adding colorful symbol lines on the surface of the hose,it looks more beautiful.
PVC Clear Hose, transparent hose pipe always conveying many liquids and gases. Also used as suds pipes andprotection of metal tubes, wooden doweling, and yacht rigging. PVC Clear hose makes it easier to view the liquid insidethe tubes, which can prevent kinks and the incorrect transfer of liquids through certain lines. Suitable for food, medicaland contact applications.PVC Clear hose piping provides a versatile, cost-effective alternative for many pipingapplications, particularly those where visual monitoring is critical.
Temperature: -10℃ ~65℃.
Specificatons Of PVC Clear Hose
| Item Code | Size | Length | W.P. | B.P. | Weight | Volume | ||||
| I.D | O.D | |||||||||
| inch | mm | mm | m/roll | psi | bar | psi | bar | kg/roll | m3 | |
| PCH-06 | 1/4" | 6 | 8 | 100 | 21.75 | 1.5 | 65.3 | 4.5 | 2.9 | 0.015 |
| PCH-08 | 5/16" | 8 | 10 | 100 | 21.75 | 1.5 | 65.3 | 4.5 | 3.7 | 0.019 |
| PCH-10 | 3/8" | 10 | 12 | 100 | 21.75 | 1.5 | 65.3 | 4.5 | 4.6 | 0.026 |
| PCH-12 | 1/2" | 12 | 15 | 50 | 14.5 | 1 | 43.5 | 3 | 4.2 | 0.019 |
| PCH-15 | 5/8" | 16 | 18 | 50 | 14.5 | 1 | 43.5 | 3 | 5.15 | 0.03 |
| PCH-19 | 3/4" | 19 | 22 | 50 | 14.5 | 1 | 43.5 | 3 | 6.35 | 0.03 |
| PCH-25 | 1" | 25 | 30 | 50 | 14.5 | 1 | 43.5 | 3 | 14.25 | 0.068 |
| PCH-32 | 1-1/4" | 32 | 38 | 40 | 14.5 | 1 | 43.5 | 3 | 17.4 | 0.113 |
| PCH-38 | 1-1/2" | 38 | 44 | 40 | 14.5 | 1 | 43.5 | 3 | 20.4 | 0.15 |
| PCH-50 | 2" | 50 | 58 | 40 | 14.5 | 1 | 43.5 | 3 | 35.8 | 0.262 |
We offer a range of reinforced PVC Clear Hose in varouis sizes. However, if none of these options are suitable for your application, can provide custom reinforced PVC tubes to meet your unique needs. PVC tubes can be custom printed with the lettering or numbering you require for easy installation and identification. Custom cutting (length), coiling, packaging and other options are available. Please contact us to discuss your custom pipe requirements.
